You are here: Products >> Android 4.1 Details |
|
|
|
|
| Android 4.1 |
| Name: |
Honda CRV-2012-android 4.1 car PC |
| Model No: |
HPT-6688 |
| Brand: |
Pengzhiying |
| Standard: |
|
|
 |
 |
| Hareware parameter |
| CPU （Main CPU） |
MST786 A9 double core, main frequency CPU,1Ghz |
| RAM |
DDR3 1G |
| Memory |
internal memory：8GB |
| Mechanism model |
DR28C(skypie DVD loader) |
| MOTOR（DVD loader） |
WFF-030SB-09210 MABUCHI |
| Pick Up Model |
X860 |
| MCU IC |
STM8AH6189 |
| Power IC model(功放IC） |
TDA7388 |
| Bluetooth Modulator |
FW3507 |
| GPS Modulator |
MSR2112 |
| TV turner Model |
RN |
| Radio Turner Model |
NXP6624 |
| Decoder IC |
Sunplus 8202T-C |
| System |
| Video decode function |
Complete format decoder |
| Operation syetem |
android 4.1.1 |
| Power on time |
For common application, 16S,For more android application,25S |
| Woring temperature |
-20°C +70°C |
| Storage temperature |
-30°C +80°C |
| Working current |
Normal, 500 mA @ 4.2V |
| input Voltage |
4.0~4.5V |
| Sleeping current |
<15 mA |
| Navigation |
| map storage |
built in or SD card |
| Map format |
Google online map, 3D map, sygic, Route 66 etc |
Navigation sofeware
memory card |
Support SD/MMC/SDHC (Max for SDHC 4GB~32GB) |
| New function |
Support radio/DVD/Bluetooth/IPOD/IPONE/SD playing
when running GPS |
| Voice navigation |
Yes |
| Show |
| Screen size |
7 inch, 16:9 TFT LCD |
Touch screen
inputting mode |
capacity touch scren |
| screen resolution |
800*480/1024*600 |
| Background picture |
dynamic interface |
| movable Function icon |
Yes |
| UI interface |
3D interface |
| Language |
| Menu language |
More than 20 languages |
| GPS language |
Vitual Voice and display language basis on map software |
| Netware |
| 3G surfing |
Support built out 3G, WCDMA or wireless hot point |
| WIFI surfing |
WIFI(built in)，support wireless surfing |
| Programe |
| File editing |
Support copy and moving file |
| Deletion |
Yes |
| Install androild APP |
Yes |
| Main function |
Support downloading and deleting 200 thousand android APP |
| desktop small APP |
Weather report、dynamic picture |
| typewriting |
Suoport Google, calendar, google translation |
| Chating communication |
Support MSN, Skype, Gmail, Twitter, Facebook, QQ, Blog etc |
| 3D games |
plan and corpse, angry bird etc |
| Audio |
| Audio type |
Support full format audio |
| Video type |
Support full format video |
| Video input type |
BT.656 input |
| Video output type |
24bit digital output |
| Audio output type |
IIS |
| Audio input type |
IIS |
| Audio |
Support POP, Jazz,dancing,classic, Rock, Normal, Normal, custom made,
hight/Low/equation, light,loud |
| Output audio amplify output |
45W x 4 |
| Ratio of noise |
>90db |
| DVD disk |
| Anti shake |
16mbit anti shake (3 disk, 10 disk) |
| Support 12cm disk |
DVD-Video, DVD±R/RW, DVD-ROM, CD-DA, CD-ROM, CD-R, CD-RW |
| Support media format |
MP3, WMA, MPEG1/2/4, JPEG, DivX, XviD，CD-DA，CD-TEXT |
| Region |
Region decode selection |
| Playing break record |
Yes |
| TV |
| Analog TV |
Support built out TV box |
| Digital TV |
DVB-T(MPEG4), ATSC, ISDB-T，CMMB etc（Optional） |
| Radio |
| AM frequency |
522-1620KHz(China)，522-1620KHz（Europe），530-1710KHz（America)，
522-1620KHz（Russian），Store 18channel |
| FM frequency |
87.5-108MHz(China)，87.5-108MHz(Europe), 87.5-107.9MHz (USA),65-108MHz
(Russia)，store 36 channel |
| RDS |
Yes |
| Bluetooth |
| Support mode |
HFP，A2DP，AVRCP |
| Main function |
Free dial optional,mobile playing music, use to receive when powering
and opening, Volume control,touch screen keyboard, mute. |
| Phonebook search |
Support A-Z searching |
| IPOD function |
| Main function |
Apple/ ipad ipod video playing，audio playing |
| Display |
Song list, art, special, composer |
| IPOD USB |
Suport IPOD, USB，support USB to read all the files of mobile |
| Other function |
| Vehicle traveling data recorder |
Support unique vehicle traveling data recorder, DVD,AVX, not effect
all the front function |
| Video OUT function |
CPU picture can be backstage video output |
| backing up video |
Auto to shift when powing off, 0 second when powering on |
| Steerng control |
20 analog setting |
| Can control |
Car state display(temperature, fan, safety belt,
scrub, door close)etc |
| USB/SD HOLE |
USB/SD (MAX 32GB or <1500 files) |
usb1.0 /connectionm support sumsung, blackberry, HTC,
motorola etc |
| Connecting port |
| |
1 3G(Built out/wifi connection |
| |
1Ipod input |
| |
1 GPS input |
| |
2 RCA output(FL/FR) |
| |
2 RCA output(Back left/Back right) |
| |
1 AUX left input |
| |
1 AUX right input |
| |
1 Subwoofer output |
| |
1 Video input |
| |
2 Video output |
| |
1 backing up video input |
|
 |
|
|
 |
|
|
|
|
